How many Lumens is this light bar?
49400lm for this light bar
spot light only light bar: is this truly spot light only? If so what’s the beam width of each lens? I’m worried about the beam being to wide which causes excessive glare off of the hood of the truck.
Hello, yes, it will be all spot, the beam width of each lens is about 25 mm.
The 54" Osram Curved LED Light Bar (312W/520W) benefits from a particularly well thought out design - its slim, beautiful and modern look will really enhance the aesthetics of your vehicle.
The 54" Osram Curved LED Light Bar (312W/520W) offers superior performance with its long-life LEDs, a maximum illumination range of 415 meters, and impressive visibility even in challenging outdoor conditions.
The 54" Osram Curved LED Light Bar (312W/520W) has a color temperature of 6000 Kelvin, similar to sunlight, and a luminous flux of 43680lm/83200lm, producing a concentrated long-range beam. Its long life (over 3000 hours) is due to the selection of high-quality Materials such as the aluminum housing, stabilized polycarbonate lens, these are very light, while also being durable and sturdy.
The 54" Osram Curved LED Light Bar (312W/520W) was also tested to reproduce extreme external conditions and to test its resistance to water, dust, shock, heat, cold and continuous vibration. These tests are carried out in din certified environmental simulation laboratories, so vx500-SP has an IP68 protection rating.
In terms of legislation, there is no need to declare amendments to the ECE certified CERTIFICATE of REGISTRATION for LED spotlights.
Therefore, 54" Osram Curved LED Light Bar (312W/520W) can be installed on touring vehicles, heavy goods vehides, agricultural machinery, site vehidles, caravans, all-terrain vehicles, and quads. This is a generic product that offers many possible applications.
54" Osram Curved LED Light Bar
- Dimensions : 54inch
Dimensions: height 3.15'' x depth 3.54''
- LED Power : 312W/520W
- 5W high intensity Osram LEDs
- Lamp Luminous Flux : 43680lm/83200lm
- Beam: 8 degree spot/90 degree flood/Combo
- Operating Voltage: 10-50V DC
- Body Color : Black
- Waterproof Rate : IP 68
- Color Temperature : 6000K
- material:Diecast aluminum housing
- lens material: PC
- Moounting bracket: Alu firm bracket
- life time：>30000hours
- Warranty : 2 Years warranty
Order details :
- 1x 54" Osram Curved LED Light Bar | Dual Row | Black Body
- 1x Universal Mount
